Anti-collision structure
A unique anti-collision design with a high-performance laser radar module ensures safe navigation in narrow and dangerous spaces.
Products Kookaburra
Available now
Kookaburra
Advanced mine mapping drone with 12-minute flight time and real-time .las file computation. Features anti-collision structure, a 10,000 lumen lighting system, and high-performance LiDAR for autonomous underground surveying.
Reference
Technical specifications
Aircraft
Aerodynamic layoutQuad-rotor
Dimensions380×380×200 mm
Weight (without battery)1118 g
Weight (with battery)1750 g
Max take-off weight1910 g
Propeller size5 inches
Battery
Battery weight632 g
Nominal voltage23.1 V
Rated capacity6000 mAh
Energy146.9 Wh
Battery life100 cycles
Charging time40 minutes
Flight performance
Flight modesSLAM / ATTI
Hover flight time12 minutes
Operation endurance≥ 10 minutes
Cruise speed2 m/s
Operational radius≥ 1.2 km
Operating temperature−10°C to 45°C
Lighting system
Lighting type40 high-efficiency LEDs
Brightness10,000 lumens
Thermal camera
Max image resolution256×192
Pixel size12 µm
Lens focal length9.7 mm
Field of view (H×V×D)18.1°×13.6°×22.6°
Min focus distance2 m
Maximum apertureF1.0
Visible-light camera
Sensor1/2.3" CMOS
Effective pixels12.3 MP
Lens apertureF2.0
Video recording4K UHD @ 60fps
LiDAR
Horizontal FOV360°
Vertical FOV−7° to 52°
Laser wavelength905 nm
Eye safety levelClass 1
Point cloud output200,000 pts/sec
Detection range40 m @10% / 70 m @80%
Near-field blind zone0.1 m
Anti-interferenceSupported
Remote controller
Operating frequency2.4 GHz + 5.8 GHz
Signal bandwidth10/20/40 MHz
Max transmission distance5000 m
Weight850 g
Operating temperature−20°C to 50°C
Operating endurance4 hours
Why it works
Core features
Smart lighting system
Up to 10,000 lumens of smart lighting for high-definition inspection and recording in complete darkness.
Specialised inspections
Built for mine shafts, furnace combustion chambers, power plant pipelines, and wind turbine blade welds — anywhere people cannot safely reach.
Resources
Documentation
Full technical documentation is released on request.
